C113928 3'' Diaphragm Kits For ASCO Pulse Valve

$16 - 17 /Set/Sets

Payment Type:

L/C,T/T,Paypal

Incoterm:

FOB,CFR,CIF,EXW

Min. Order:

1 Set/Sets

Transportation:

Ocean,Land,Air,Express

Port:

Ningbo,Shanghai,Guangzhou

Contact Now

 Chat Now

Product Description

Product Attributes
Supply Ability & Additional Information
Packaging & Delivery

< >

Overview

Product Attributes

Model No.: C113928

Brand: Brando

Origin: China Ningbo

Certification: CE

Product Name: Pulse Valve Diaphragm

Diaphragm Material: Nbr, Fkm

Packaging: Individual Plastic Bag

1 Set: 1pc Big Diaphragm, 1pc, Small Diaphragm, 1pc Spring

Fitted Valve Port: 3''

Fitted Valve Model: Scxe353.060

Supply Ability & Additional Information

Packaging: Plastic bag, Box, Carton, Pallet

Productivity: 100000 sets per month

Transportation: Ocean,Land,Air,Express

Place of Origin: China Ningbo

Supply Ability: 20000 sets per week

Certificate: CE

Port: Ningbo,Shanghai,Guangzhou

Payment Type: L/C,T/T,Paypal

Incoterm: FOB,CFR,CIF,EXW

Packaging & Delivery

Selling Units:: Set/Sets

Package Type:: Plastic bag, Box, Carton, Pallet

C113928 3'' Diaphragm Kits For ASCO Pulse Valve

Pulse jet valves are indirect operated solenoid valves especially designed for dust collector systems. When the solenoid is energized, trapped air above a diaphragm is quickly exhausted causing a high pressure difference across the diaphragm. Thereby the diaphragm is suddenly opened. When the solenoid is de-energized, air escapes through a hole to the chamber above the diaphragm which balances the pressure and instantly closes the valve.

Diaphragm C113928 was suittabled for ASCO pulse valve, SCXE353.060(SCEX353.060), SCG353.060. The diaphragm is made of BUNA/NBR, the size is 3".

Nitrile: -10~ 85 degrees

Viton: -10~200 degrees

Main Dimension of SCXE353.060 Pulse Valve Diaphragm:

A060-2

Ordering Code of Diaphragm For ASCO Pulse Valve:

Valve Port Size	Pulse Valve Model	Diaphragm Model	Diaphragm Material (FKM is also available)
3/4''	SCG353A043	C113444	TPE (White), NBR (Black)
1''	SCG353A044
3/4''	SCG353-052
1''	SCG353-053
3/4''	SGG353A043
1''	SGG353A044
3/4''	SGG353-052
1''	SGG353-053
1 1/2''	SCG353A047	C113827	NBR
	SGG353A065
2''	SCG353A050	C113685, C113686	NBR
2 1/2''	SCG353A051
3''	SCXE353.060	C123432, C123433	NBR
	SCG353D060
3/4''	G3530A41	C113443	NBR
1''	G353A042
3/4''	G353-055
1''	G353-056
1 1/2''	G353A045	C113825	NBR
	G353-066
1 1/2''	G353A046	C113826	NBR
	G353A063
2''	G353A048	C113684	NBR
2 1/2''	G353A049

Pictures of Pulse Valve Membrane Production:

More ASCO Type Pulse Jet Valve for you to choose:


Threaded Type	Remote Pilot Type	Straight Through Type	Submerged Type

Valve Diaphragm	Solenoid Coil	Solenoid Armature	Pulse Controller
